Siam YUKEN Co., Ltd.
TOP Siam YUKEN Co., Ltd. Product List Supply high-concentration, high-speed zinc bright plating chemicals, Thailand
  • Supply high-concentration, high-speed zinc bright plating chemicals, Thailand

Supply high-concentration, high-speed zinc bright plating chemicals, Thailand

High Concentration and High-Speed Chloride Zinc Plating Bath
METASU FZ-77M2（T) is a high-speed zinc plating bath process that achieved plating at a speed of 3μm/minute for the first time.
It can cover a wide range of applications, from high-speed zinc plating to high-speed plating for cast iron.
＜Special Features＞
・It is a high-speed plating process at a rate of 3μm/minute.
・Can perform in-line zinc plating (In-Line).
・Can solve problems such as separation of the plating solution and high zinc concentration, which are specific issues of high-speed plating.
・Can continuously use the stabilized plating solution because the problem of plating solution separation has been resolved.
Product Specifications
Appearance
External Appearance : Light yellow to light brown liquid（FZ-77M2(T))
Light yellow to yellowish-brown liquid（ZB-627G(T)）
Operating Conditions (Standard)
Composition : Zinc metal 30～50g/L
Ammonium chloride : 180～250g/L
METASUFZ-77M2（T） 0.05～0.2L/KAH
METASUZB-627G（T） 0.01～0.40L/KAH
Conditions : ｐH 5.7～6.0
Bath temperature : 20～30℃：increases with increasing speed
Cathode current density : 3～12 A/d㎡
Anode current density : 5 A/d㎡ max
Anode purity : 99.99%
Anode current shield : Required
Agitation : Strong air agitation or spraying (Air agitation recommended)
Filtration : Continuous filtration 2～3 cycles/Hr
