Siam YUKEN Co., Ltd.

Distributor of barrel plating, corrosion resistance, and white bronze coating for Thailand

Trivalent Chromium White Silver Passivation Agent
Metas YFE-M is a trivalent chromium white silver passivation agent for barrel processing, designed for zinc chloride plating baths, offering excellent self-healing properties and heat and corrosion resistance.
＜Features＞
・It is a passivation agent utilizing trivalent chromium.
・Corrosion resistance is equivalent to or better than hexavalent chromium yellow chromate agents.
・It possesses self-healing properties.
・Heat and corrosion resistance is enhanced.
・Conventional chromate treatment equipment can be used.
　(In some cases, heating equipment for the treatment solution will be required.)
・Since it contains almost no organic substances, wastewater treatability is good.
Product Specifications
Properties
Appearance Deep blue strongly acidic liquid (Metas YFE-M)
Transparent colloidal liquid (Metas YFE-HR)
Reddish-brown acidic liquid (Metas YFE-C1(T))
Deep blue strongly acidic liquid (Metas YFE-SR3)
Bath Makeup Conditions
Chemicals Used Usage Range
Metas YFE-M 100-250ml/L
Metas YFE-HR 40-100ml/L
Metas YFE-C1(T) 1-5ml/L
Operating Conditions
Item Range Remarks
Treatment Temperature 30-50℃
Treatment Time 30-60 seconds
pH 1.8-2.2 Please check the pH before use. If the pH is outside the specified range,
please adjust with caustic soda solution.
Agitation To ensure uniform concentration of the treatment solution, please perform gentle pump agitation.
For oscillation agitation of the basket containing parts, it is desirable to set a stop time of 5-6 seconds before lifting to prevent scratches.
Replenishment Conditions
Chemicals Used Replenishment Guideline (Standard)
Metas YFE-SR3 75ml/100dm2
Metas YFE-HR 10-15ml/100dm2
＊Please adjust the pH so that it falls within the operating conditions range.
