TAKISAWA (THAILAND) CO., LTD.

TCC-2100L3 High-Precision 8-Inch Chuck CNC Lathe

The TCC-2100L3 is an 8-inch chuck CNC lathe provided by TAKISAWA. With a high-rigidity bed design and precision control, it ensures stable and high-accuracy machining. It is ideal for machining automotive parts, precision machinery components, and aerospace parts.
■ Features
- High-Rigidity Design: A robust bed structure ensures stability even under high-load machining conditions.
- High-Precision Spindle: Advanced control technology maintains superior machining accuracy even at high rotational speeds.
- Versatile Machining: Supports a wide range of machining needs, including center work and chuck work.
- Automation Compatibility: Integrates with robots and loaders, enabling labor-saving and unmanned operations.
- Intuitive Operation: A user-friendly CNC control panel reduces operator workload.
■ Specifications
- Chuck Size: 8 inches
- Turret Type: 8-station turret (direct mount) / 12-station turret (direct mount)
- Maximum Machining Diameter: φ350mm (8-station turret) / φ320mm (12-station turret)
- Maximum Machining Length: 289mm (8-station turret) / 291mm (12-station turret)
- Bar Work Diameter: φ51mm (Option: φ42mm)
- Spindle Speed: 3200 min⁻¹ (Options: 2500, 4100, 5000, 6000 min⁻¹)
- Rapid Traverse Speed: X-axis: 24m/min / Z-axis: 30m/min
- Spindle Motor Power (15, 30 min/Continuous): 11/7.5kW
- Machine Height: 1700mm
- Required Floor Space: 1420×1525mm
- Machine Weight: 2530kg
■ Applications
- Precision machining of automotive components
- High-accuracy machining of aerospace parts
- Manufacturing of industrial machinery components
- Machining of precision electronic device parts
The TCC-2100L3 combines precision machining with enhanced productivity, meeting the diverse needs of the manufacturing industry.
■ For more details, please download the PDF or feel free to contact us.
