AddForceCut and TungFeedBlade High-strength grooving and parting tools
With an advanced clamping system and modular blade design, AddForceCut and TungFeedBlade can provide stability and increase production efficiency in deep grooving and large workpiece cut-off operations.
AddForceCut is a high-rigidity grooving and cut-off tool from Tungaloy, featuring a unique self-clamping system that ensures stability in deep grooving and large workpiece cut-off. TungFeedBlade is a modular blade system that accommodates AddForceCut inserts, enabling increased feed rates and enhanced production efficiency.
■ Features
- AddForceCut Clamping System
Clamps the insert with 3 contact points, ensuring stability and precision in deep grooving operations, along with a bottom insert support that precisely returns the cutting edge to its original position.
- TungFeedBlade Modular Blade Design
The triangular blade features 3 insert pockets, allowing each blade to be used up to 3 times, reducing tooling costs and setup time.
- High-Speed Feed Capability
The TungFeedBlade system, when used with CHTBR/L tool blocks, enables high-speed feeding, increasing production efficiency by 30-50 percent.
- Large Workpiece Cut-off Capability
The TungFeedBlade system can handle cut-off operations for workpieces up to 120 mm in diameter to meet diverse machining requirements.
■ Specifications
- Insert Geometry: Available with QGM and QGS inserts, featuring two 3D chipbreaker types to support a wide range of materials.
- Material: Utilizes AH7025 PVD coated grade, which provides a balance between wear resistance and toughness to accommodate various machining conditions.
The combination of AddForceCut and TungFeedBlade enhances stability and efficiency in deep grooving and large workpiece cut-off operations. The advanced clamping system and modular blade design address diverse machining requirements and support efficient production.
■ For more details, please download the PDF or inquire as convenient.
