Custom Depth Gauge Precise Tool for Deep Holes, Narrow Grooves & Micro Parts

Custom depth gauges provide accurate measurements in hard-to-reach areas such as deep holes, narrow grooves, and small parts. Ideal for industries requiring precision and consistency, this tool ensures operator-independent inspection for complex geometries.

■ Accurate Measurement in Hard-to-Reach Areas
Standard measuring tools often struggle to access deep or narrow spaces, especially in parts with complex geometries. HANEDA (Thailand) offers custom depth gauges designed specifically for pinpoint inspection—even in challenging areas like micro holes or insert positions.

■ Target Industries
・ Automotive: gear cases, oil grooves, bolt hole inspections
・ Electronics: plastic housings, sockets, PCBs
・ Medical: micro-holes, step components
・ Manufacturers seeking consistent in-line measurement tools

■ Product Features
・ Precision: ±0.01 mm or better accuracy
・ Tip Options: needle, flat, cross-type for various part geometries
・ Body Materials: stainless steel (SUS), aluminum, MC nylon
・ Gauge Types: handheld, desktop, fixed-block designs
・ Functions: supports single-point and multi-point measurement
・ Usability: intuitive operation minimizes skill dependency

■ Production Process
・ Based on CAD data or real sample
・ Custom tip design for specific locations (holes, grooves, steps)
・ High-precision CNC machining with lapping finish
・ CMM inspection included with full report
・ Measurement depth: up to 100 mm or per customer spec

■ Advantages of Thai Manufacturing
・ Rapid delivery: 5–7 working days post design confirmation
・ Cost-efficient: Japanese engineering at local Thai prices
・ Support: Local service for design changes or urgent remake
・ Trilingual support: Japanese, Thai, and English engineers available

■ Example Applications
・ Bolt hole depth checks in engine components
・ Die-cast groove inspection tools
・ Mold insert cavity depth gauges
・ Micro-depth probes for electronic housings

■　For more details, please download the PDF or feel free to contact us.
