Transparent PVC Tubing QX‑PVC 600 ｜ Non-Shrink Cable Protection for Easy Inspection

QX‑PVC TUBE 600 is a transparent, non-shrink PVC tube that provides 600V insulation while allowing for visual inspection of internal wiring. Ideal for factory control panels and automated systems, it enhances both safety and maintenance efficiency.

■ Transparent non-shrink tubing with insulation and visibility
QX‑PVC TUBE 600 is a transparent, non-shrink type PVC tube developed for industrial cable insulation. With no need for heating, it simplifies on-site installation and retrofits. The transparent structure allows visual inspection of internal wires and terminals, making it highly suitable for quality checks, preventive maintenance, and process control in manufacturing environments.

■ Key Specifications and Performance
・ Material: Transparent PVC (non-shrink type)
・ Rated Voltage: 600V
・ Outer Diameter Range: 2.0mm – 17.0mm (20 standard sizes)
・ Wall Thickness: 0.45mm – 0.50mm (varies by size)
・ Flame Retardancy: UL VW-1 compliant
・ Operating Temperature: -20℃ to 85℃
・ Tensile Strength: ≥10.4MPa (1.5kgf/mm² or more)
・ Elongation: ≥100％
・ Dielectric Strength: ≥2500V (60 seconds)
・ Volume Resistivity (after aging): ≥10⁴Ω·cm

■ Features and Differentiators
・ Transparent body: Enables quick visual checks of wire connections and aging
・ Non-shrink structure: No heating required, improving work efficiency and safety
・ High electrical performance: Rated for 600V with excellent insulation durability
・ Wide size variety: Supports diverse applications in compact and large systems

■ Applicable Industries and Use Cases
QX‑PVC 600 is ideal for:
・ Wiring insulation in industrial control panels
・ Cable management in office automation and communication devices
・ Transparent protection in medical and laboratory equipment
・ Visual monitoring in factory automation (FA) and robotic wiring
・ Electrical inspections in smart factory environments

Especially beneficial where both high voltage protection and visual clarity are essential.

■ Why Choose QX‑PVC TUBE 600
・ Transparent non-shrink PVC for visibility and safety
・ Rated 600V with high flame retardancy for industrial reliability
・ Reduces work time by eliminating heating
・ Domestic stock in Thailand for fast supply (subject to inventory confirmation)

■ For more information, please contact us or download the product catalog below.
