MIKI PULLEY (THAI) CO., LTD.

C&Bunits

This Miki Pulley catalog details a comprehensive range of electromagnetic clutches and brakes, encompassing electromagnetic-actuated (micro, standard, and integrated units), spring-actuated brakes, electromagnetic tooth clutches, brake motors, and power supplies. Products are designed for connection and release, offering compact form factors and integrated functions for complex actions, with configurations such as drip-proof, open-disc brake systems, motor-coupled, and speed reducer-integrated units, including double-clutch models. Torque capacities range from 0.4 N·m for micro units to 2200 N·m for electromagnetic tooth clutches, operating typically at DC24V, with customizable options for DC12V, 90V, or 180V, within -10 to +40°C and up to 3000 min⁻¹ rotation speed. Applications are broad, covering articulated robots, special-purpose vehicles, aerial vehicles, wind turbine generators, forklifts, and various manufacturing equipment like printing, bookbinding, woodworking, and semiconductor machinery. Technical specifications include detailed selection guides based on application, torque, performance, and load properties, with formulas for calculating motor torque (TM = 9550*P/(nr*η)), load torque (Te = l*F), required torque (T = (Ta ± Te)K), and engaging/braking energy (Ee = J*nr^2 / (182 * (Td/(Td-Te)))). The catalog also outlines operating time considerations, stopping precision (Δθ = ±0.15θ), mounting guidelines (flange/bearing-mounted stators, armature types, air gap adjustment, fitting tolerances), and control circuit design, emphasizing DC/AC rectification, surge protection with varistors, overexcitation for faster response, and environmental resilience against temperature, humidity, dust, and vibration. Customization for friction materials, voltages, and integrated solutions is also available.
