Shape restoration of worn or damaged mold parts│Precision additional machining & EDM│Reverse engineering from sketches without drawings

Gate Asia (Thailand) Co., Ltd. provides restoration and repair services for worn or damaged precision mold parts in Thailand. Even without drawings, we support reverse engineering from physical parts or sketches, leveraging advanced EDM and high-precision grinding to assist in the rapid recovery of production lines.

Table of Contents

1. Reverse Engineering and Drawing Creation from Physical Parts or Sketches
2. High-Precision Shape Restoration and Additional Machining via EDM and Grinding
3. Rapid Replacement Part Production via China & Asia Network
4. Service Range & Specification Table
5. Main Machine List
6. Frequently Asked Questions (FAQ)

Reverse Engineering and Drawing Creation from Physical Parts or Sketches

It is common for spare parts to be needed for molds used for many years or equipment from overseas manufacturers where "drawings are lost" or "data is missing due to old design." Facing refusals from manufacturers to produce parts without drawings or having to spend significant time on redesign directly correlates to the risk of line shutdowns.

We support reverse engineering (Reverse Engineering) where we create official drawings (Drawing) after micron-level measurements of worn or damaged physical parts or handwritten sketches. Our specialized team organizes the requirements and coordinates with engineers in China to reproduce the optimal design.

By undertaking everything from drawing creation to machining (Machining), we enable stable procurement of obsolete parts and eliminate the risk of production delays due to inadequate drawing management.

High-Precision Shape Restoration and Additional Machining via EDM and Grinding

When mold parts are chipped or dimensions can no longer be maintained due to wear, remaking everything from scratch is inefficient in terms of cost and time. On the other hand, if the repair accuracy is insufficient, it may adversely affect the entire mold once production restarts.

Equipped with numerous die-sinker EDM machines from Sodick and Mitsubishi Electric, as well as precision form grinders, we can perform precise additional machining and shape restoration even for high-hardness heat-treated steel or Carbide. We remove damaged areas and re-machine or correct micro-shapes at the micron level.

Opting for repair (Repair) using high-precision machining technologies maximizes mold life and significantly suppresses procurement costs compared to manufacturing entirely new parts.

Rapid Replacement Part Production via China & Asia Network

Repair cases requiring restoration of complex shapes or procurement of special materials (e.g., Carbide, Titanium) that are difficult to handle with local facilities in Thailand alone tend to have longer lead times.

We have built a strong network of over 100 partner factories in China (and over 200 worldwide). We send reverse engineering data from Thailand to our China base, and under the management of Japanese staff stationed locally, high-precision replacement parts are manufactured and delivered in as little as 14 to 19 days. With our standard 14-19 day delivery cycle, customers can effectively plan to minimize production line downtime.

※For more details, please download the attached materials or contact us via the form below.

Service Range & Specification Table

Main Machine List

You can check the full list of machines at this link: https://thai.emidas.com/en/gateasia/facility

Frequently Asked Questions (FAQ)

Q. Can we consult even if drawings are not yet finalized?

Yes. We can work from simple sketches. Our team will coordinate and relay information to our China base to create official drawings and propose the most suitable specifications.

Q. How do you inspect 2-micron tolerances?

We implement a quality assurance system at our Chinese subsidiary (local entity) using CMMs and projectors to perform incoming inspections directly from the manufacturing factories. We only deliver products that meet Japanese standards for quality.

Q. Is there a cost benefit for single-unit custom orders?

Yes. Our China network specializes in high-mix, low-volume production. Even for a single unit, we can manage production costs and shipping to provide a competitive price compared to manufacturing in Thailand or Japan.

Q. Do you provide after-sales support in Thailand?

For repairs after delivery, it is handled on a case-by-case basis. Since these are special parts, we usually recommend returning them to the original manufacturing factory to ensure the best accuracy and quality.

※For more details, please download the attached materials or contact us via the form below.
