TSUBAKI Zip Chain Lifter - High-Precision Chain-Driven Lifting System | TSUBACO KTE

TSUBACO KTE CO., LTD. handles TSUBAKI ZIP CHAIN LIFTER in Thailand. It supports applications for auto-assembly lines and clean room environments.

Table of Contents

• Product Overview
• Main Specifications
• Product Features
• Main Applications
• Frequently Asked Questions (FAQ)

Product Overview

The Tsubaki Zip Chain Lifter is a lifting device utilizing unique "Zip Chain" technology, where two chains interlock like a zipper to form a single, rigid pillar for elevation. Compared to traditional hydraulic lifters, it enables high-speed and high-frequency operation while achieving precise lifting in a compact installation space.

Main Specifications

Basic specifications based on technical documentation are as follows:

• Lifting Speed: Max. 80 m/min
• Operating Frequency: Max. 480 cycles/hour
• Maximum Load: 50 kg
• Maximum Stroke: 2,000 mm
• Power Supply: 200 VAC
• Motor Output: 850 W Servo Motor
• Frame Material: Aluminum + Stainless Steel

Product Features

• High-Speed and High-Frequency Operation: Supports a lifting speed of up to 80 m/min and an operating frequency of 480 cycles per hour. It is suitable for production lines where reducing cycle time is essential.
• High Stopping Accuracy and Multi-Point Positioning: Servo motor control allows for positioning at the millimeter level. It supports multi-point stopping at any desired height, enabling the construction of complex conveying processes.
• Clean Structure and Durability: Since it does not use hydraulic systems, there is no risk of oil leakage, making it ideal for clean room use. The exterior is constructed from aluminum and stainless steel, featuring a resin cover for easy internal monitoring. It is designed for high durability with an expected service life of over 1,000,000 cycles.

Main Applications

• Workpiece lifting in auto-assembly lines
• Conveying in clean environments such as food and pharmaceutical factories
• Lifting units in limited installation spaces
• Conveying processes requiring high-precision positioning

Frequently Asked Questions (FAQ)

Q: Can it be used in clean rooms?
A: Yes. The hydraulic-free design eliminates the risk of oil leakage, making it optimal for clean environments.

Q: What is the service life of the device?
A: It features a high-durability design capable of over 1,000,000 operating cycles.

※For more information, please download the PDF attached to this article or contact us via the form at the bottom of the page.
